GE i12L Intraoperative Probe Ultrasound Transducer

Medical Ultrasound Transducer Probe

NAME:

GE i12L Intraoperative Probe Ultrasound Transducer

P/N:

GE i12L

BANDWIDTH/FREQUENCY:

4 - 12 MHz (Logiq P5 Premium)

4.5 - 11.5 MHz (Logiq 7, Logiq 9, Logiq S6)

5 - 11 MHz (Logiq P5, P6, P6 Pro)

5 - 12 MHz (Logiq 5 Pro)

FEATURES:

Number of Element: 96 (Logiq 5 Pro)

Convex FOV (Max): 25 mm (Logiq 5 Pro)

B-mode Imaging Frequency: 6.0, 8.0, 10.0 MHz (Logiq 5 Pro)

Harmonic Frequency: 8, 10 MHz (Logiq 5 Pro)

Doppler Frequency: 5.0, 6.7 MHz (Logiq 5 Pro)

Steered Angle: +/- 20 degrees (Logiq 5 Pro)

Footprint: 29 x 10 mm (Logiq 5 Pro, Logiq 7, 9, P5 Premium, S6), 12 x 32 mm (Logiq P5, P6, P6 Pro)

APPLICATIONS:

Intraoperative

Small Parts

Vascular

Pediatrics

Neonatal (Logiq P5, P6, P6 Pro)

COMPATIBILITY:

This transducer is compatible with the following ultrasound machines / systems

Logiq 5 Pro

Logiq 5 Expert

Logiq 7

Logiq 7 Dimension

Logiq 9

Logiq P5

Logiq P5 Premium

Logiq P6

Logiq P6 Pro

Logiq S6

WARRANTY

One years after receiving item.
