3 Channels Portable ECG Machine Measure Cardiovascular Disease With Automatic Interpretation

Ask Lasest Price
Brand Name :	SINOHERO
Model Number :	SE508
Certification :	CE&ISO
Payment Terms :	L/C, D/A, D/P, T/T, Western Union,
Supply Ability :	1000PC/Week
Delivery Time :	3-7 week days

Add to Cart

Product Details
Company Profile

3 Channels Portable ECG Machine Measure Cardiovascular Disease With Automatic Interpretation

Product Description

- Sharp and Clear 3.5 inch TFT screen

- 12 leads ECG simultaneously display

- Built-in Database and store more than 1000 pieces of ECG data

- Digital signal processor for filter feature

- Auto-measurement, auto-analysis and auto interpretation functions

- Ergonomic and compact design with handle

- Both AC and DC power supply with built-in lithium rechargeable battery

Specification

Size and Weigh

· Size:315mm(L)x215mm(W)x75mm(H)

· Net Weight: 2.25Kg

· 3.5lnch ColorTFTdisplay

· Resolution:320x240 pixels or hlgher

ECG Instrumentlnput

· Measurement parameters:HR,P-R interval, P-Duration,

QRS DurationQ-T interval, -Tc,PAxis,

QRS Axis, TAxis, R(V5),S(V1),R(V5)+S(V1)

· SafetyType: Classl,Type CF

· Lead: Standard12 leads

· lnput Way: Floatlng and defibrillation protectlon

· Patientleak current:<10uA

· Sampling Rate: 1000Hz

· A/D conversion: 12bit

· Frequencyresponse:0.05Hz-150Hz(-3dB)

· lnput impedance: t 50MΩ

· Time constant: Time constant>3.2s

· CMRR: >60dB, >100dB(Addfilter)

Accessories

Enduring polarization voltage:±500mV

· Noiselevel:≤15µVp-p

Dispose wave data

· EMG interferencefilter: 25Hz/35Hz(-3dB)

· AC filter: 50Hz/60Hz(11l 20dB)

Printing output

· Recording Way: Thermal Printing System(8spots/mm)

· Recording paper: 80mm(W)x20m(L)

· Paperspeed: 6.25mm/s,12.5mm/s, 25mm/s,50mm/s

· Sensitivity choice:2.5,5,10,20,40mm/mVStandard

sensitivity is10mm/mV+0.2mm/mV

Power supply

· AC: 220V, 50Hz(110V,60Hz)

· DC: 7.4V, 3700mAh rechargeablelithium polymer battery

Fuse Specification

· 2pcs ll)5x200mmACtimelag;T250mA/250V(Power Supply: 220V)

Option

· ECG-Sync software package
